- Size: 0.5*0.5*0.918
- Place of Origin: Shandong Jinan
- Brand Name: Over the head
- Model Number: FY-PT450
- Weight: 60.000 kg
Model
FY-PT450
spinning speed
Level 0.01 ° ~ 45 ° / S; Pitch 0.01 ° ~ 30 ° / S
Rotation angle
Level 0 ~ 360 °; Pitch -45 ° ~ 45 °
Preset
200
Preset Accuracy
Up to ± 0.05 °
auxiliary switch
Group 2, passive, normally open
Lens Presets
Support, adaptive variety of lenses
Automatic cruise
8, each point can be set to 10 cruise
OSD menu
Optional
Automatic homing
1 to 60 minutes can be set to automatic homing time
Auto Scan
1
Protocol
Pelco-D, Pelco-P Optional
Communication baud rate
2400/4800/9600/19200 bps optional
Communication Interface
RS485 support angle queries return (optional RS422, instantaneous feedback)
Network Interface
Optional
Lens defrost
Optional
Air-cooled shield
Optional
Heating
Optional
Input Supply Range
AC220V ± 20%, 50 / 60Hz / AC24V ± 20% (optional) / DC48V ± 20% (optional) / DC24V ± 20% (optional)
Total power consumption
≤180W (no heating) ≤230W (heating)
Operating temperature
Up to -25 ℃ ~ 55 ℃, 90% ± 3%, non-condensing (optional -40 ℃ ~ 65 ℃)
Storage temperature
Up to -40 ℃ ~ 65 ℃
Wind rating
12
Maximum load
25kg
Protection class
IP66
Total Weight
60KG
Dimensions
500mm × 500mm × 918mm (L × W × H)
