- Size: 0.265m*0.18m*0.315m
- Place of Origin: Shandong Jinan
- Brand Name: Over the head
- Model Number: FY-SP2510
- Weight: 12.500 kg
model
FY-SP2510
spinning speed
Level 0.01 ° ~ 60 ° / S;
Pitch 0.01 ° ~ 30 ° / S;
Rotation angle
Level 0 ~ 360 ° continuous rotation; tilt 20 ° ~ -60 °;
Preset
200
Preset Accuracy
± 0.1 °
Position, focal length, etc. return
Optional
auxiliary switch
Group 2, passive, normally open
Lens Presets
Support, adaptive variety of lenses
Lens speed control
Zoom, focus adjustable speed control
Automatic cruise
8, each point can be set to 10 cruise
Automatic homing
1 to 60 minutes can be set to automatic homing time
Auto Scan
1
Protocol
Pelco-D, Pelco-P Optional
Communication baud rate
2400/4800/9600/19200 bps optional
Communication Interface
RS485 support angle queries return (optional RS422, instantaneous feedback)
OSD menu function
Support (optional)
Input Supply Range
AC24V ± 20%, 50 / 60Hz; DC28V ± 20%
Total power consumption
≤70W
Operating temperature
-25 ℃ ~ 65 ℃, 90% ± 3%, non-condensing (optional -40 ℃ ~ 65 ℃)
Storage temperature
-40 ℃ ~ 70 ℃
Maximum load
10Kg
Destinations
Top load (side load optional)
transfer method
Worm gear
Protection class
IP66
Total Weight
12.5Kg
Dimensions
265mm × 180mm × 315mm (L × W × H)
