- Size: 0.35m*0.206m*0.38m
- Place of Origin: Shandong Jinan
- Brand Name: Over the head
- Model Number: FY-SP5035
- Weight: 23.000 kg
model
SP5035
spinning speed
Level 0.01 ° ~ 20 ° / S;
Pitch 0.01 ° ~ 10 ° / S;
Rotation angle
Level 0 ~ 360 ° continuous rotation; tilt 45 ° ~ -45 °;
Preset
255
Preset Accuracy
± 0.1 °
Position, focal length, etc. return
Optional
auxiliary switch
Group 2, passive, normally open
Lens Presets
Support adaptation variety of lenses
Automatic cruise
8, each point can be set to 10 cruise
Automatic homing
1 to 60 minutes can be set to automatic homing time
Auto Scan
1
Protocol
Pelco-D, Pelco-P Optional
Communication baud rate
2400/4800/9600/19200 bps optional
Communication Interface
RS485 support angle queries return (optional RS422, instantaneous feedback)
OSD menu function
stand by
Input Supply Range
AC24V ± 20%, 50 / 60Hz; DC28V ± 20%
Total power consumption
≤80W
Operating temperature
-25 ℃ ~ 65 ℃, 90% ± 3%, non-condensing (optional -40 ℃ ~ 65 ℃)
Storage temperature
-40 ℃ ~ 70 ℃
Maximum load
35Kg
Destinations
Top load (side load optional)
Protection class
IP66
Total Weight
23Kg
Dimensions
350mm × 206mm × 380mm (L × W × H)
